Description
Material: Special brass CuZn40Al2/So. Pressure angle 15.The gear wheels can only be used with worms having the same centre distance and the same transmission. * Worm only polished - worm gear with helical gearing.** The figures stated for the efficiency are only reference values, since - besides the lead angle - also mounting, lubrication, speed and assembly have an influence on the efficiency.Transmission [i]75 : 1Module0,6No. of Teeth75Helix Angle []0202dA [mm]47,0Max. Torque Nm at 2800 [rpm]7,3Weight [g]143
